Screw sealing varnish. Green color. 20 ml tube.
The essential tool for protecting, marking, sealing and locking all types of screws and as proof of tampering. Lackfabrik Bäder GmbH & Co. KG is specialized since 1962 in the production of sealing lacquers for screws (paints for sealing / marking) for many industries, in particular the automotive diesel.

Modulares System zum Testen der von Zexel hergestellten nockenwellenlosen Pumpen der Größen PFR1K.., PFR2K.., PFR3K.. und PFR4K..
Das Cambox kann auf jedem Prüfstand für Diesel-Einspritzpumpen eingesetzt werden.
Diese Konfiguration wird in einer Holzkiste geliefert und umfasst die folgenden Komponenten:

- Universal Cambox (9562-M1) und Distanzstück (9562-M4 und 9562-M5)
- 4-Zylinder-Nockenwelle (9564-A)
- Befestigungsplatte für Zexel PFR .. 1K (9562-T)
- Befestigungsplatte für Zexel PFR .. 2K (9891)
- Befestigungsplatte für Zexel PFR .. 3K (9892)
- Befestigungsplatte für Zexel PFR .. 4K (9893)
- Stangen (9562-F und 9562-L) und Kraftstoffkontrollstecker (9562-G, 9562-R und 9562-LB)
- Cambox-Montageflansch (9478-BXS)
- Antriebskupplung (9576)

Interface (adapter with rod) for 9664-N on Bosch VE pumps

Adapter to test nozzles on pop tester application on Land Rover Discovery pumps

Solenoid wrench BOSCH UIS IVECO application.
Similar to BH 0 986 613 239

Interface (adapter with rod) for 9664-N on Denso VE pumps

Manual press for spring drive small blocks of the governor, BH P pumps bearings, CAV DPC-DPS bearings, BH EV/VE… bushings.

Technische Spezifikationen:
- Zentrierhöhe: 110 mm
- Führung 20 mm

Hand pump for calibrating and checking the operations of
the diesel injectors
- precise adjustment of the injection pressure (adjust the
opening pressure of the injection nozzle)
- control of the spray atomization (pattern and vibration
characteristics)
- control tightness (leaks)
- equipped with bypass valve for the manometer.
Dial: 0 - 600 bars gliceroil
Tank fitted with a filter
Supplied with 2 connection pipes: 14-14 and 14-12 mm

17 mm octagonal nozzle retaining nut wrench, 27mm hexagonal drive

Neues verstärktes Klammerpaar für PE (S)… P..P und P7800

Assortment of 850 calibrating shims for Bosch CRI and CRIN injectors.
List of contents:
8210-R04 from 1.20 to 1.66, every 0,02 mm (5 pcs each thickness)
8210-R05 from 1.20 to 1.66, every 0,02 mm (5 pcs each thickness)
8210-R06 from 1.20 to 1.66, every 0,02 mm (5 pcs each thickness)
8210-R07 from 1.20 to 1.66, every 0,02 mm (5 pcs each thickness)
8210-R13 from 1.14 to 1.25, every 0,01 mm (5 pcs each thickness)
8210-R28 from 8.40 to 8.51, every 0,01 mm (5 pcs each thickness)
8210-R29 from 8.40 to 8.51, every 0,01 mm (5 pcs each thickness)
8210-R34 from 0.99 to 1.10, every 0,01 mm (5 pcs each thickness)
8210-R35 from 0.99 to 1.10, every 0,01 mm (5 pcs each thickness)
8210-R41 from 1.19 to 1.10, every 0.01 mm (5 pcs each thickness)

Wrench to fix/remove the flange, shaft and pulley on the following pumps ZEXEL VP. The timing pin is included.

Flange for fixing ZEXEL VP pumps on test benches. It requires the universal bracket 9680-A)

N10 wrench socket for the valve retaining screw on Bosch CRIN 3 injectors, 1/2" drive.
Similar to 0 986 613 632
