InjectionPower 충성도 프로그램은 펌프 및 인젝터 수리를 다루는 사람들을 위해 특별히 설계된 장점을 갖춘 플랫폼으로, 5000 EUR 이상을 우수하게 투자할 계획입니다.
STARTER, PREMIUM 및 ELITE 프로필을 사용할 수 있습니다.
멤버십은 매년 자동으로 갱신됩니다.

> > >아래에 설명된 각 계층의 자세한 기능과 이점을 참조하세요.

Modular system for testing the camshaftless pumps manufactured by Zexel, with sizes:
- PFR1K.., PFR2K.., PFR3K.. PFR4K..
- PFR3KD, PFR4KD
- PFR3MD, PFR4MD
The cambox can be applied on any test bench for the diesel fuel injection pumps.
This configuration is supplied in one wooden box and includes the following components:

- Universal Cambox (9562-M1) and spacer (9562-M4 and 9562-M5)
- 4 cyl camshafts (9564-A and 9564-E)
- Fixing plate for Zexel PFR .. 1K (9562-T)
- Fixing plate for Zexel PFR .. 2K (9891)
- Fixing plate for Zexel PFR .. 3K (9892)
- Fixing plate for Zexel PFR .. 4K (9893-D)
- Fixing plate for Zexel PFR .. 3KD/MD (9562-MD3)
- Fixing plate for Zexel PFR .. 4KD/MD (9562-MD4)
- Rods (9562-F and 9562-L) and fuel control connector (9562-G, 9562-I, 9562-R and 9562-LB )
- Cambox mounting flange (9478-BXS)
- Drive coupling (9576)

The Injector Clinic Basic module includes:
- Test bench for testing injectors individually, one by one
- Triggering unit programmable, by microchip cards
- Cables for electromagnetic Bosch, Delphi, Denso injectors
- Training course with the release of the vocational qualification certificate
- Assorted calibrating shims for Bosch injectors
- Station for measuring thicknesses (with digital millesimal gauge)
- Precision instrument for detecting the ball lift
- Ultrasonic cleaning box
- Magnifier on adjustable arm, with built-in lighting
- Tool for regenerating the ball seat valves (Bosch)
- Professional microscope

The Pro-EM module includes the supply of specific tools for maintenance the Bosch, Delphi, Denso electromagnetic common rail injectors. In details:
- Universal operational station
- Torque wrench
- sockets for actautor and valves
- Tools for assembly / disassembly
- testing device for electromagnetic actuators

ERT45R 제어 장치는 모든 테스트 벤치와 호환되는 전자 제어 디젤 분사 펌프용으로 설계된 범용 테스트 시스템의 핵심입니다. 이 혁신적인 시뮬레이터는 광범위한 연구를 통해 개발되었으며, 스마트카드(마이크로칩 카드)를 통해 프로그래밍할 수 있는 다재다능한 장치가 탄생했습니다. 이 기능은 최신 운영 요구 사항과 완벽하게 일치합니다.
ERT45R은 장기 투자로, 현재 21개의 옵션을 제공하는 다양한 프로그래밍 키트를 통해 쉽게 확장할 수 있습니다. 각 키트에는 프로그래밍 카드(소프트웨어), 단계별 그림이 있는 자세한 사용 설명서, 기본 케이블(길이 2m) 및 특정 펌프 커넥터에 맞게 조정된 어댑터 케이블이 포함되어 있습니다. 간단한 설정으로 기능을 위해 최소한 하나의 프로그래밍 키트가 필요하므로 ERT45R은 작업 환경에서 유연성과 효율성을 보장하면서 테스트 기능을 향상시키려는 전문가에게 필수적인 도구입니다.

High accuracy electronic tool to test and trig the electromagnetic actuator of Bosch CRI and CRIN injectors and automatically relief the ball lift for the 3rd stage repair.

The flange 8155-E warrants the centered clamping of the majority of cr pumps (Bosch CP1, CP3, CP4, Delphi, Denso, VDO), on any test bench.
The flange is equipped with 4 rings of reduction to suite the 50, 60, 68, 80 mm hub diameters, as well as CP1K pumps.
The flange requires 9680-A universal cradle or similar.

Specifications:
- external diameter: 6 mm
- internal diameter: 2 mm
- thickness: 2 mm
- length: 600 mm
- nuts: M14x1,5 mm - M12x1,5 mm
Similar to Bosch reference 1 680 750 014, Hartridge AHP117, Denso 95091-10260

Swivel vice for Common-rail pumps

Corresponding to Bosch reference 0 986 611 562 - KDEP 1027, Zexel 157829-4620

17mm 원추형 조인트를 통해 CAV DPA 펌프(암 스플라인 샤프트 장착)를 구동하기 위한 어댑터 인터페이스. 스플라인 수형 인터페이스, 테이퍼형 수형.

Reinforced swivel base, for mounting / dismounting the injection pumps at the workbench.

Tool box for assembly, disassembly and timing of CAV DPC pumps (17 particulars).

Hand pump for calibrating and checking the operations of the diesel injectors
- precise adjustment of the injection pressure (adjust the opening pressure of the injection nozzle)
- control of the spray atomization (pattern and vibration characteristics)
- control tightness (leaks)
- equipped with bypass valve for the manometer.
Dial: 0 -> 400 bars.
Tank fitted with a filter
Supplied with 2 connection pipes: 14-14 and 14-12 mm

Similar to 0 986 611 754, KDEP 1085, 1 680 110 630.

Two handles spanner eyelet 17 mm, eyelet 19 mm, eyelet 22 mm, hex. 22 mm

Dial gauge bracket for rod stroke. Thread 24x1,5 protusion 18 mm for PE…P pumps

Universal clamping bracket to hold several flanges allowing the centered clamping of flanged diesel injection pumps.
The 125 mm centering height and 20mm guide (Bosch standard) can be adapted to different requirements, by the proper adapting spacers.
