The ERT45R system

ERT45R 제어 장치는 모든 테스트 벤치와 호환되는 전자 제어 디젤 분사 펌프용으로 설계된 범용 테스트 시스템의 핵심입니다. 이 혁신적인 시뮬레이터는 광범위한 연구를 통해 개발되었으며, 스마트카드(마이크로칩 카드)를 통해 프로그래밍할 수 있는 다재다능한 장치가 탄생했습니다. 이 기능은 최신 운영 요구 사항과 완벽하게 일치합니다.
ERT45R은 장기 투자로, 현재 21개의 옵션을 제공하는 다양한 프로그래밍 키트를 통해 쉽게 확장할 수 있습니다. 각 키트에는 프로그래밍 카드(소프트웨어), 단계별 그림이 있는 자세한 사용 설명서, 기본 케이블(길이 2m) 및 특정 펌프 커넥터에 맞게 조정된 어댑터 케이블이 포함되어 있습니다. 간단한 설정으로 기능을 위해 최소한 하나의 프로그래밍 키트가 필요하므로 ERT45R은 작업 환경에서 유연성과 효율성을 보장하면서 테스트 기능을 향상시키려는 전문가에게 필수적인 도구입니다.

Adapter cable for BMW 318 pumps, fitted with test data ( BH 0 986 612 443)

Adapter cable for Ford pumps BH VE (BH ref. 0 986 612 446)

Tests and ohmic measurements should be obtained with a multimeter, to be used in conjuction with OTA.
The measuring point are fixed, so that the operator has the hands free.
The combination of the electric contacts is obtained by easily rotating the two knobs, like a game.
Function similar to Bosch 0 986 611 929.

Adapter cable for Bosch rotary pumps VE..L 585, VE..R 635 (Fiat, Alfa, Lancia, Chrysler), VE..L 715, VE..L 736 (Nissan) (BH ref. 0 986 612 442), fitted with test data

Adapter cable for BH pumps VE..L460, VE..L460-1, VE..L460-2, VE..R530, VE..R530-1 (Audi) - 0 986 612 440, fitted with test data

Adapter cable for BH (VW) rotary pumps, fitted with test data (BH 0 986 612 444)

Adapter cable for BH pumps VE..R 510, VE..R510-1, VE..R 590, VE..R 600, VE..R 638, VE..R 640, VE..R 650, VE..L550, VE..L 650, VE..L 649 (Audi - Volkswagen - Volvo) - 0 986 612 439, fitted with test data

Similar to Bosch reference 0 986 612 430 - KDEP 1865/1.

The ERT45R Programming Kit enhances the functionality of the ERT45R control unit, specifically for testing Caterpillar C6.6 and C4.4 common rail pumps.
By leveraging the available features, Diesel Fuel Injection Specialists are equipped to conduct a comprehensive range of tests with confidence, achieving both precision and reliability in evaluating the performance of this type of pumps.
The specialized software together with the cables are crucial for professionals aiming to deliver high-quality service in fuel injection system diagnostics, thereby improving overall operational efficiency.

Set of tools for the installation of the test bench for industrial pumps: C/rail DENSO HP0 NE SENSOR flanged pump (094000-0342) and BOSCH C/rail CP2 pumps.
Universal Test Bench crandle
Sensor holder
Coupling with reference notch cone 30
Universal mounting flange complete with O-ring

Set of tools for the installation of the test bench for C/rail pumpsDENSO HP0 G Sensor (094000-480) and NE 2 Sensor (094000-0240):
Pair of supports H=75 mm with adapter plate
Adapters plate for RPM sensor
Coupling reference notch cone 25

Set of hydraulic connections for CATERPILLAR C6.6 pumps

Items included:
- Backflow by-pass set for CP2/HP0 pumps(**)
- Test pipes with propers adapters fittings for CP2/HP0 pumps
- External flowmeter for common-rail Hevy-Duty pumps

(**) This item is strictly required as the feeding capacity of the test bench's pump is not enough to ensure the correct feeding of low pressure (440 liters / hour)

The kit includes:
- program card to allow the ERT45R Simulator to actuate the necessary functions to test this type of pumps
- Set of cables for C/rail DENSO HP0 pumps: NE Sensor flanged (094000-0342) and NE with 2 sensors (094000-0240).
- Set of cables for C/rail DENSO HP0 pumps G Sensor (094000-480)
- Illustrated step-by-step instructions manual
