The ERT45R system

ERT45R 控制單元是專為電控柴油噴射幫浦設計的通用測試系統的核心，可與任何測試台相容。這種創新的模擬器是透過廣泛的研究開發出來的，是一種可透過智慧卡（微晶片卡）進行編程的多功能設備。此功能完全符合現代操作要求。
ERT45R 是一項長期投資，可以透過選擇可用的程式套件輕鬆擴展——目前有 21 個選項可用。每個套件包括一張編程卡（軟體）、一份帶有逐步插圖的詳細說明手冊、基礎電纜（長 2 公尺）以及專為特定泵連接器定制的適配器電纜。透過簡單的設置，至少需要一個程式套件來實現功能，這使得 ERT45R 成為尋求增強測試能力同時確保工作環境的靈活性和效率的專業人士的必備工具。

Adapter cable for BMW 318 pumps, fitted with test data ( BH 0 986 612 443)

Adapter cable for Ford pumps BH VE (BH ref. 0 986 612 446)

Tests and ohmic measurements should be obtained with a multimeter, to be used in conjuction with OTA.
The measuring point are fixed, so that the operator has the hands free.
The combination of the electric contacts is obtained by easily rotating the two knobs, like a game.
Function similar to Bosch 0 986 611 929.

Adapter cable for Bosch rotary pumps VE..L 585, VE..R 635 (Fiat, Alfa, Lancia, Chrysler), VE..L 715, VE..L 736 (Nissan) (BH ref. 0 986 612 442), fitted with test data

Adapter cable for BH pumps VE..L460, VE..L460-1, VE..L460-2, VE..R530, VE..R530-1 (Audi) - 0 986 612 440, fitted with test data

Adapter cable for BH (VW) rotary pumps, fitted with test data (BH 0 986 612 444)

Adapter cable for BH pumps VE..R 510, VE..R510-1, VE..R 590, VE..R 600, VE..R 638, VE..R 640, VE..R 650, VE..L550, VE..L 650, VE..L 649 (Audi - Volkswagen - Volvo) - 0 986 612 439, fitted with test data

Similar to Bosch reference 0 986 612 430 - KDEP 1865/1.

The ERT45R Programming Kit enhances the functionality of the ERT45R control unit, specifically for testing Caterpillar C6.6 and C4.4 common rail pumps.
By leveraging the available features, Diesel Fuel Injection Specialists are equipped to conduct a comprehensive range of tests with confidence, achieving both precision and reliability in evaluating the performance of this type of pumps.
The specialized software together with the cables are crucial for professionals aiming to deliver high-quality service in fuel injection system diagnostics, thereby improving overall operational efficiency.

Set of tools for the installation of the test bench for industrial pumps: C/rail DENSO HP0 NE SENSOR flanged pump (094000-0342) and BOSCH C/rail CP2 pumps.
Universal Test Bench crandle
Sensor holder
Coupling with reference notch cone 30
Universal mounting flange complete with O-ring

Set of tools for the installation of the test bench for C/rail pumpsDENSO HP0 G Sensor (094000-480) and NE 2 Sensor (094000-0240):
Pair of supports H=75 mm with adapter plate
Adapters plate for RPM sensor
Coupling reference notch cone 25

Set of hydraulic connections for CATERPILLAR C6.6 pumps

Items included:
- Backflow by-pass set for CP2/HP0 pumps(**)
- Test pipes with propers adapters fittings for CP2/HP0 pumps
- External flowmeter for common-rail Hevy-Duty pumps

(**) This item is strictly required as the feeding capacity of the test bench's pump is not enough to ensure the correct feeding of low pressure (440 liters / hour)

The kit includes:
- program card to allow the ERT45R Simulator to actuate the necessary functions to test this type of pumps
- Set of cables for C/rail DENSO HP0 pumps: NE Sensor flanged (094000-0342) and NE with 2 sensors (094000-0240).
- Set of cables for C/rail DENSO HP0 pumps G Sensor (094000-480)
- Illustrated step-by-step instructions manual
